Click to enlarge
SX-150
Back to products
Z-30/20 N

SX-180

Max Working Height 186 ft | 56.86 m
Max Horizontal Reach 80 ft | 24.38 m
Below Ground Reach 2 ft | 0.61 m
Platform Capacity 750 lb | 340 kg
Machine Width and Length 16 ft 6 in / 47 ft | 5.03 m / 14.33 m
Compare
Add to wishlist
Categories: ,
Description

The highest reaching model in the line-up, the Genie® SX™-180 telescopic boom lift offers operators access to jobsites inaccessible by other booms, boom trucks and cranes. It is purpose-built to work on jobsites in the oil and gas industries and in industrial or commercial construction and in general maintenance applications.

Overview

• Genie XChassis™ system extends and retracts to provide stability on the job and a narrow profile for transport
• 3.05 m (10 ft) rotating jib with 135˚ vertical and 60˚ horizontal articulation to easily position workers and gear
• Standard 2.44 m (8 ft) self-levelling platform with an unrestricted capacity of 340 kg (750 lb)
• Drive-enable at full height for more productivity on the jobsite
• Tackles the most extreme jobs with a working height of 56.9 m (186 ft) and horizontal reach of 24.4 m (80 ft)
